The Task

I've recently been working on a project to automatically generate English flashcards with a blend of AI and APIs to fetch data, and a template of some sort to slot it into. For the latter part, I've spent significant time researching. I've come across different Js frameworks like Paper.js, but eventually settled on utilizing raw, generated SVG files. SVGs are a great type of image file to generate, since they follow a strict XML format, and thus can have text or base64 images injected into them with ease.

SVGs are Awesome

SVGs really are great. They're a undervalued file format that can be used for so, so much more than just icons and simple graphics. They allow you to easily integrate countless different elements in xml form, like <animate> and <path>. You can slot in <foreignObject>s to add external elements like such...

1<!-- Inspirational quote -->
2<foreignObject x="0" y="41" width="126" height="24">
3    <xhtml xmlns="http://www.w3.org/1999/xhtml">
4        <p class="inspirational-quote">
5            "{{ INSPIRATIONAL_QUOTES_1 }}"
6        </p>
7    </xhtml>
8</foreignObject>

<iFrame>s, and all other HTML and even some js goodies become real possibilities. css styles can be added natively, including classes and all. However, when you begin to slot in external sources like this, problems arise when it comes to rendering the svgs into self-contained PDFs or rasterized JPG/PNG images.

The external imports and HTML elements that I'm loading into my SVGs prevents most libraries that already exist from importing them, likely as either a security precaution, or perhaps because externally defined data is hard to render. Something I noticed, however, is that Chrome has no issue with loading complex SVGs with imports. Chrome is a full fledged browser, so it makes sense that it has baked-in support for all the external elements I may include.

But how does this help me render SVGs? Well, as it turns out, Chrome provides a great renderer too. It's a bit clunky, and maybe not an ideal solution, but it works well and consistently.

Printing to PDFs

Chrome Devtools PDF Printing

To render SVGs with chrome, I first turned to its printing functionality. Importantly, Chrome lets you print not just to printers, but also to PDF files directly. The settings are highly customizable, and let you export SVG super easily to a PDF.

Just like with regular printing, Chrome provides options for setting the page layout, along with adding margins (which, since I'm not actually planning to print my SVGs, could be set to 0), setting a page range, and more. With the devtools protocol, which is essentially a way to computationally interact with the printing API, even more options become possible. With the API, Chrome allows for the file to be exported as a data stream or base64 data string, which would allow me to not have to do additional file handling.

Loading up a chrome driver

The first step of the process is to load up a chrome driver. I decided to externalize this step, loading up a chrome driver in a separate "engine" module, so that I wouldn't need to load in a new chrome driver for each PDF conversion. In the past I've used Pyppeteer, a fork of Puppeteer to automate Chrome, for various unrelated projects. However, since Pyppeteer is now no longer maintained, I decided to explore Selenium, a different popular browser automation library, instead. After some research, I came across many StackOverflow articles like this one, explaining how I could take advantage of the Chrome DevTools Protocol command Page.printToPDF to run the print command. Since my goal was to avoid needless file handling, I didn't plan on using the exact code from StackOverflow, but it would be a good starting point, and showed that my planned procedure was indeed a possibility.

1import atexit
2import os
3
4from selenium import webdriver
5from selenium.webdriver.chrome.service import Service
6from webdriver_manager.chrome import ChromeDriverManager
7
8# Install chromium if it isn't already installed
9service = Service(ChromeDriverManager().install())
10
11chrome_options = webdriver.ChromeOptions()
12# Kiosk printing makes it so that the print dialog GUI is hidden. Since I'm using headless
13# chrome, I believe this just reduces the compute to interact with the print-to-pdf API, since
14# it wouldn't be shown anyway, but may still be rendered. This seems like a common flag for
15# printing to PDF, so I included it since it didn't hurt.
16chrome_options.add_argument("--kiosk-printing")
17# Disable's the UI. Not needed, but makes things faster and things work on CLI only computers.
18chrome_options.add_argument("--headless")
19# Printing to PDF shouldn't require a GPU.
20chrome_options.add_argument("--disable-gpu")
21# The sandbox seems to prevent tabs from messing with each other, as a security feature. Since
22# we're 'hacking' Chrome to render PDFs, making Chrome lighter any way we can is ideal.
23# https://www.google.com/googlebooks/chrome/med_26.html (comic I found that helps explain it)
24chrome_options.add_argument("--no-sandbox")
25
26# Create the webdriver, and make sure that it closes properly when Python exits
27webdriver_chrome = webdriver.Chrome(service=service, options=chrome_options)
28atexit.register(webdriver_chrome.close)

Webpage Injection 'Hack'

As aforementioned, something important for the rendering process is for it to be able to be done purely in memory. My project utilized templated SVGs, so writing rendered templates in their SVG form to disc for the sole purpose of loading them into Chrome only to dump them back to dic would be extremely redundant. So, I devised a solution.


Chrome's about:blank

Injected image

To do this, first I opened an about:blank page. I knew I'd want to resize the image to fill the entire viewport, but I'd also want to resize the viewport to be the exact size that I wished for my final export to be. For this, I used Chrome devtools' Emulation.setVisibleSize command. Then, I sent the following javascript to the browser to inject the image.

1document.body.style.margin = '0';  // remove the default document margin
2const content = document.createElement('img');  // create the <img> element
3content.src = 'data:{mimetype};base64,{data}'; // inject the svg as a b64 image
4content.style.width = '100%';  // maximize the image
5content.style.height = '100%';
6document.body.appendChild(content); // inject the image

'Printing' the PDF

Now comes the most important step: actually printing to a PDF. This step was super simple: just a Chrome devtools command. Check it out...

1webdriver_chrome.execute_cdp_cmd(
2"Page.printToPDF",
3    {
4        "printBackground": False,
5        "landscape": False,
6        "displayHeaderFooter": False,
7        "scale": 1.5, # chrome seems to add some extra margin when printing, even
8        # when the margins are set to 0. I just scaled up a bit to account for this.
9        "paperWidth": 1.75, # the width of the document I'm dealing with, in inches
10        "paperHeight": 2.5, # the height in inches
11        "marginTop": 0,
12        "marginBottom": 0,
13        "marginLeft": 0,
14        "marginRight": 0,
15    }
16)["data"]  # grab the b64 encoded PDF

Potential

The cool thing with SVGs is that not only can you write them out in a text editor easily, but you can also template them. I'm not going to go too far into that procedure here, but here's a simple example of utilizing SVGs as a document template for an English vocab flashcard. The idea is that you can slot in {{ FIELD_NAME }} jijna2 (templating engine) fields, slot in your own data (whether fetched from an API, user entered, AI generated, or what not), and then render it to a PDF.

This is just the start, and feel free to reach out if any other SVG-related ideas come to mind!
